In-wall system BERNSTEIN for wall-wc 805 black
If you want to give to your bathroom an exclusive atmosphere, the in-wall system BERNSTEIN 805 with included cistern is the right product for you.
The rapid assembly doesn´t need intervenction on the wall structure, which makes this system absolutely easy to install.
High-quality aluminium frame and tempered glass frontal plate give stability and elegance to the whole structure.
The cistern is conceived with an adjustable amount of water, partial or total rinse, and anti-condensation technology.
The surface is smooth and easy to clean.
Important note : the wall-hung toilet NT2040 ist not compatible with our sanitary module In-wall system 805.
As always BERNSTEIN is a guarantee of quality!
Product details
Dimensions | 1003,5 x 483 x 108 mm |
Frame | Aluminum |
Fontal plate | Tempered glass (ESG) 8mm |
Colour | Black |
Installation | Exterior |
Rinse | Complete or partial |
Flow rate | Adjustment of the rinse system: Flow rate 6 l (rinse volume: 4,8 - 7,4 l) Flow rate 3 l (rinse volume: 2,4 - 3,5 l) |
Water pressure | 0,7 - 7,5 Bar |
Water temperature | 4 - 35° C |
Room temperature | 3 - 40° C |
Classe of protection | IPX4 |
Weigth | Net 19,85 kg, gross 21,5 kg |
Flushplate | |
Lateral water entrance (see image) | |
Freestanding |
Technical drawings
(click on the image for larger view)
Download
Included in the delivery
- In-wall system BERNSTEIN 805
- Flushplate
- Assembly material
- Instructions
Delivery
This product is dispatched by DHL package and takes up to 4-5 working days to reach you. The carrier will try to deliver your package at home. In case you were not in when this happens, a delivery note will be left in your mail box, you can then collect the item at your local post office.
For deliveries to islands, additional charges will apply for sea transport . In order to calculate this charge with precision, your postal code (ZIP Code) will be required.
Question : Kann ich den Wasseranschluss auch im Sanitärmodul anschließen?
From : customer
Answer:
Guten Tag, vielen Dank für Ihre Anfrage.Dies ist durch einen Flexschlauch möglich.Genügend Platz befindet sich von hinten betrachtet in der rechten oberen Ecke.Mit freundlichen GrüßenBERNSTEIN-BADSHOP
Question : Kann ich den Abwasserablauf auch unterhalb des Sanitärmoduls in einen Bodenablauf einführen und nicht in die Wand
From : customer
Answer:
Guten Tag, vielen Dank für Ihre Anfrage. Eine denkbare Lösung für eine solche Gegebenheit wäre es, die Rückwand um ca. 2-3cm auszustemmen und Ihren bestehenden Senkrechtabfluss dorthin zu verlegen. Die Abflüsse haben in der Regel einen Durchmesser von 100mm. Unser Sanitärmodul ist mit seinen 110cm Gesamttiefe extra schmal und bietet standardmäßig nicht genügend Platz für einen klassischen Senkrechtabfluss. Das Sanitärmodul ist ursprünglich für den Waagrechtablauf konzipiert.Mit freundlichen GrüßenBERNSTEIN-BADSHOP
