Product information "Walk-In Nano EX103 10 mm Super White glass - profile colour & width selectable"

Walk-In Nano EX103 10 mm Super White glass - profile colour & width selectable

EX103 is made of 10mm toughened safety crystal-clear Super White glass with NANO coating. Compared to conventional float glass, the Super White Glass, with low-iron metal oxide content, reduces green reflections. Its colour is therefore extremely neutral and allows very realistic colour reproduction of objects behind it.


The aluminium wall profile - 30 mm wide - is surface-mounted and can compensate wall unevenness up to 10 mm. The walk-in shower enclosure is suited for floor level with shower drain or shower tray installation.
Available options include a walk-In shower enclosure in different sizes, an adjustable support bar available in a round or square design, a ceiling support bar and the possibility to select a high gloss chrome or matt black profile. Use the menu at the top of the page to make your choice.

Please note: From a glass width of 130cm, support bar is absolutely recommended. The wider the glass, the more the shower screen can lose stability.

Installation with ceiling support bar: We recommend ceiling installation up to a maximum distance of 400 mm between the shower wall and the ceiling !.



Product details

Wall profile material Aluminium
Profile colour options: high-gloss chrome, matt black
Glass type Super White Glass with a nano-coating | especially clear glass with a strongly reduced green sheen
Glass thickness 10 mm toughened safety glass (single-pane safety glass in accordance with DIN-EN 12150)
Height 200 cm
Width available in: 90 cm, 100 cm, 110 cm, 120 cm, 130 cm, 140 cm, 150 cm, 160 cm
Nano-coating Water and soap residues run off - limescale barely has a chance to develop
Additional details
  Wall profile - width 30mm - suitable for surface and flush mounting| Compensate wall uneveness up to 10 mm
  Adjustable support bar from approx. 80 - 140 cm | High-quality stainless steel | Glass connection can be rotated 360°
  Ceiling support bar can be cut to from 20 - 40 cm | High-quality stainless steel
  From a glass width of 130 cm, assembly with support bar or ceiling support bar
  Suited for floor level or tray installation.
  Easy to install thanks to detailed assembly instructions
  Decorative items not included



Weight and packaging per glass panel

Width   Shipping weight   Packaging
90 cm   48 kg   205 x 92.2 x 5.5 cm
100 cm   53 kg   205 x 102.2 x 5.5 cm
110 cm   58 kg   205 x 112.2 x 5.5 cm
120 cm   64 kg   205 x 122 x 5.5 cm
130 cm   68 kg   205 x 132.2 x 5.5 cm
140 cm   73 kg   205 x 142.2 x 5.5 cm
150 cm   79 kg   205 x 152.2 x 5.5 cm
160 cm   84 kg   205 x 162.2 x 5.5 cm



Download

Download PDF Icon Assembly InstructionsEX103



Assembly

This item is easy to assemble.



Maintenance and cleaning

  • Hygenical and easy to clean
  • NANO coating ensures a quick and smooth maintenance
  • Wide surface, every corner can be easily reached when cleaning



Delivered items

  • Super White Glas Walk-In Shower Enclosure
  • Incl. wall profile (in the selected colour)
  • Optional: Ceiling support bar and support bar (from 130cm selected support included)
  • Assembly material
  • Assembly instructions



Delivery

Pallet shipments are delivered curbside. Please consider that the carrier will call you to fix delivery date/time, so kindly remember to indicate your phone number (landline or mobile phone) when placing your order.

For deliveries to islands, additional charges will apply for sea transport. In order to calculate this charge with precision, your postal code (ZIP Code) will be required.

Concealed of the screw connections: yes
Enclosure height: 200cm
Glass thickness: 10 mm
Hinges: Flexible
Material: ESG safety glass, aluminum
Nano coating: with Nano coating
Product line: EX103
Profile colour: chrome, matt black
Profile material: aluminium
Profile type: frameless
Shower installation: floor-even, on shower tray
Special features: without stabilisation bar
Type of shower doors: Walk-in
Version: Walk-In Shower
Width: 90cm, 100cm, 110cm, 120cm, 130cm, 140cm, 150cm, 160cm
